Power Distribution Panel

01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)

01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)

₹1,25,000.00
01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)
01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)
01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)
01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)
01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)
01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)
01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)
01313 (D'MAK Power Distribution Panel- D'MAK/2025-26/01313)
New

We are a leading manufacturer of power distribution panel (also known as panelboard, breaker panel, or electric panel) which is a component of an electricity supply system that divides an electrical power feed into subsidiary circuits while providing a protective fuse or circuit breaker for each circuit in a common enclosure. Our valuable clients can avail an extensive range of PDP Panel from us. Manufactured utilizing best quality raw material, this range of products is in line with the international quality standards & parameters. Widely known for its superior performance, energy efficiency, sturdiness and longer functional life, this range is highly applauded by our clients all across the nation. Moreover, in order to ensure defect free products, our highly skilled quality controllers check this range on various quality parameters.

BOQ DESCRIPTIONMAKECATALOG NUMBERQTYAction
250A 4P 35kA MCCB, TMD Release (Fixed Thermal Magnetic), Type: DMC
DMAKDMC4P250M11
Red Color LED Indicator 22.5 mm, Voltage: 220V AC
VALIAN/A11
Blue Color LED Indicator 22.5 mm, Voltage: 220V AC
VALIAN/A11
Yellow Color LED Indicator 22.5 mm, Voltage: 220V AC
VALIAN/A11
250/5A 15VA Acc. Cl: 1 Tape Insulated Ring Type Current Transformer, ID: 110mm.
REPUTEDN/A44
Multifunction Meter, 3Ph, Acc. CL: 0.5, 6 digit 1 Line, 4 Digit 3 Line Red LED Display, CT Ratio Selectable upto 5/5 to 6000/5A AC, Parameters: V (P-P), V (P-N), Phase Current, KW, KWh, PF, KVA, KVAr, Hz, Load Hr/ No Load Hr., RPM, Voltage: 100-270V AC, Size: 96x96, Model: AVH-14
MULTISPANAVH-1411
8 Stage Intelligent Power Factor Controller (1CT), Type : IPFC CS 1001, Size: 144x144
HAVELLSQHOSBS5N000811
6A 1P 10kA C-Curve MCB
DMAKDM1P633
63A 4P 10kA C-Curve MCB
DMAKDM4P6366
32A 2P 10kA C-Curve MCB
DMAKDM2P3222
100A 4P 35kA MCCB, TMD Release (Fixed Thermal Magnetic), Type: DMC with Spreader Link
DMAKDMC4P100M22
25A 4P 10kA C-Curve MCB
DMAKDM4P2514
10kVAr, 3Ph, Splendid Duty, Cylindrical Type, 440V AC Capacitor
HAVELLSQHUTCC5010X014
10kVAr 3Ph Capacitor Duty Contactor, Coil: 240V AC, Aux. Contact: 1NO, Type: HGS
HAVELLSIHPHE010110N14
Red Color LED Indicator 22.5 mm, Voltage: 220V AC
VALIAN/A14
Green Spring Return Metallic Push Button 22.5 mm
JIGOJG-BA3114
Red Spring Return Metallic Push Button 22.5 mm
JIGOJG-BA4214
1NO Contact Block
JIGOJG-ZBE-10114
1NC Contact Block
JIGOJG-ZBE-10214
2-Position Metallic Selector Switch
JIGOJG-BD2114
6A 1P 10kA C-Curve MCB
DMAKDM1P614
16A 4P 10kA C-Curve MCB
DMAKDM4P1614
5kVAr, 3Ph, Splendid Duty, Cylindrical Type, 440V AC Capacitor
HAVELLSQHUTCC5005X014
5kVAr 3Ph Capacitor Duty Contactor, Coil: 240V AC, Aux. Contact: 1NO, Type: HGS
HAVELLSIHPHE005110N14
Red Color LED Indicator 22.5 mm, Voltage: 220V AC
VALIAN/A14
Green Spring Return Metallic Push Button 22.5 mm
JIGOJG-BA3114
Red Spring Return Metallic Push Button 22.5 mm
JIGOJG-BA4214
1NO Contact Block
JIGOJG-ZBE-10114
1NC Contact Block
JIGOJG-ZBE-10214
2-Position Metallic Selector Switch
JIGOJG-BD2114
6A 1P 10kA C-Curve MCB
DMAKDM1P614
160A 4P 35kA MCCB, TMD Release (Fixed Thermal Magnetic), Type: DMC
DMAKDMC4P160M11
Red Color LED Indicator 22.5 mm, Voltage: 220V AC
VALIAN/A11
Blue Color LED Indicator 22.5 mm, Voltage: 220V AC
VALIAN/A11
Yellow Color LED Indicator 22.5 mm, Voltage: 220V AC
VALIAN/A11
160/5A 15VA Acc. Cl: 1 Tape Insulated Ring Type Current Transformer, ID: 110mm.
REPUTEDN/A33
VAF Meter, 3Ph/1Ph, Acc. CL: 0.5, 3 Digit 3 line Display, CT Ratio Selectable upto 6000/5A AC, Parameters: Avg. V(L-L), Avg. V(L-N), Hz, Load Hr/ No Load Hr., RPM, Voltage: 230V AC, Size: 96x96, Model: AVF-19D
MULTISPANAVF-19D11
